75-Ton Air Handler
Air handlers are essential components of your HVAC system, responsible for cooling and purifying large volumes of air within your facility or warehouse. Our 75-ton system is a versatile, high-performance machine ready to seamlessly slide within your setup to bolster your daily operations.
At TCRS, we offer rental air handlers that are ready to transport to your facility immediately. We have your best interests at heart and will do everything we can to deliver a hassle-free experience that keeps your projects on track with suitable temperature solutions.
What Do Air Handlers Do?
Air handlers work with your heating and cooling units to efficiently deliver air throughout warehouses, shops and other facilities. They're typically used within ducted forced air systems, striving to manage the air temperature before being pushed through your ventilation ducts. These electric systems have three main components: an air filter, a blower and evaporator coils.
Air enters the handler and moves through a filter where dirt and debris are removed. It then passes over the evaporator coils, which absorb excess heat to cool the air to the desired temperature on the thermostat. Once conditioned, the blower circulates the air out of the handler and into the ducts, moving throughout the various areas in your facility.
75-Ton Air Handler Specifications
Check out this air handler's specifications to ensure it's the right one for your application:
Dimensions: Our 75-ton air handler is 164 inches long, 96 inches wide and 103 inches tall. You can leverage this information to find the ideal location for your rental handler in your facility.
Weight: This handler weighs around 6,000 pounds, excluding additional attachments and the water you pump through it.
Air source: The air handler is compatible with various sources, including return and external air. It moves and receives air through six 20-inch connections to maintain exceptional performance.
Airflow rate: During operation, this air handler can efficiently cycle between 14,000 to 27,000 standard cubic feet of air per minute.
Water flow rate: This 75-ton system can move 240 gallons of water per minute when properly chilled at 44 degrees Fahrenheit.
Common Air Handler Applications
This powerful air handler is rated to hold a practical 75 tons of cooled air to support your operations confidently. Plus, its configurable supply, return air panels and vari drive control provide a smooth and uninterrupted performance no matter how your needs change. Due to its strength and versatility, countless professionals trust its use for several activities around the facility, including:
Climate control
Comfort heating
Temporary cooling
Moisture removal
Warehouse temperature control
Product storage
Material production
Contact TCRS to Start Your Rental Today
TCRS is the partner you can count on to deliver high-quality air handlers capable of creating a comfortable and safe environment for your employees, equipment and products. We offer convenient and customizable rental agreements and 24/7 emergency solutions to give you the resources you require when you need them most.
Request a quote for our 75-ton air handler with customized pricing that fits the timeline of your situation. Get in touch with our specialists to learn more about our solutions and discover how we can support your workflow.
