RENTAL AIR CONDITIONERS: 80-TON AC UNIT
80-Ton Rental AC Unit
Keeping a building or large area cool is something many people often take for granted. The absence of an adequate cooling system can have serious consequences, especially during the warmer months when needed most. When needed for an outdoor installation, planned shutdown, or emergency call for the most reliable air conditioning rental solutions, Temperature Control Rental Solutions (TCRS) is ready to help.
With over 30 years of industry experience, we'll help you select the best air conditioning rental option that fits your needs. TCRS will stand by your side throughout the process, from selection to installation to operational training.
How the TCRS 80-Ton Air Conditioning Unit Works
Our 80-ton rental unit is entirely self-contained and features scroll compressors. These devices work by taking in ambient or return air and using the compressors to remove the heat.
The specialty design allows for larger temperature drops on 100% ambient conditions compared to standard air conditioners. The blower has a vari-drive controller allowing the airflow to be adjusted from 50% up to 100% of the design flow to match your application. Temperature can be controlled by supplying air, returning air, or remotely. Condensers are designed to work in extreme environments up to 120 °F.
The air conditioning system works continuously to maintain a cool environment.
Specifications for Our 80-Ton AC Rental Units
The TCRS 80-ton air conditioning unit provides the cooling you need for large spaces in outdoor and large indoor applications. These units feature a 480-volt, three-phase power connection to deliver maximum cooling.
The primary specifications include:
Dimensions: The 80-ton units measure 9'1" high, 8' wide, and 15'2" long.
Capacity: These units have a cooling capacity of 80 tons and feature 20-inch duct connections.
Weight: The total shipping weight for our 80-ton models is 10,300 pounds.
Temperature input: 67 to 80 degrees Fahrenheit
Temperature output: 54 to 55.7 degrees Fahrenheit
Common Applications for 80-Ton Air Conditioning Units
Our 80-ton rental units arrive at your facility quickly with minimal setup needed. These units are perfect for cooling in large spaces, warehouses, commercial buildings, universities, new construction, and more.
Some typical applications include:
Industrial and commercial spaces.
Hospitals and universities.
Turbine and motor cooling.
New construction and dehumidification.
Warehouse facilities.
Restoration.
Temporary construction sites.
Technical Specifications
| Electrical
Cooling load Heating load Minimum circuit ampacity (cooling only) Recommended Fuse / Circuit Breaker Rating |
179 amps 192 amps 250 amps 300 amps |
| System Control
Outside air damper Space temperature control Discharge air temperature control Return air temperature control |
Manual Standard Standard (4 x 20" Supply Air Duct) Standard (4 x 20" Return Air Duct) |
| Fan Data
Design air flow / maximum air flow Design total static pressure Fan type Fan control Motor power / speed Duct Connections Filter (Reusable) |
18,000 cfm, 23,000 cfm 4 in wg Plenum VFD 30 hp / 1725 rpm 20" ea. 2" (30% efficient) |
| Cooling Data
Design capacity Entering air temp (dry bulb/wet bulb) Leaving air temp (dry bulb/wet bulb) Coil construction Rows Fins per inch |
75 Tons 80.0 / 67.0°F 55.7 / 54.0°F Cooper tube / Aluminum fins 8 8 |
| Heating Data
Type Capacity Heating |
Electric 130 kW 444 MBH |
| Compressor Data
Type Crankcase heat |
Screw 200 watts |
Rental-Ready for Your Temporary Use
Part of being rental-ready means that you can operate our equipment without being an expert. The controls and displays on our units are easy to use. Our team of specialists will provide the necessary training upon installation.
Renting an air conditioning unit instead of purchasing one can be a wise choice that keeps your operations up and running. If you face either a planned or emergency cooling loss, we are the rental network you can rely on for a fast response. We offer flexible rental agreements with durations that align with your schedule.
Choosing TCRS for Your Air Conditioning Rental Needs
At TCRS, our experienced and knowledgeable representatives are ready to walk you through the entire rental process, from equipment selection to a customized rental agreement and installation. To learn more about our 80-ton rental unit and how we can help serve your air conditioning rental needs, call us at 877-343-8277 or contact us online today.
