RENTAL HEATERS: 150kW ELECTRIC HEATER
150kW Electric Heater
From planned maintenance projects to unexpected seasonal emergencies, this 150kW heater delivers powerful temporary heating when you need it most. What's more, it offers affordable convenience, control, and security.
Our unit uses a single-pole mount receptacle for the ultimate plug-and-go convenience, and it operates with a simple on/off switch. Maintain consistent temperature with programmable logic controls and a variable blower speed control. Take the guesswork out of maintenance with an hour meter that displays time in service and indicator lights for safe operation.
Additional safety features abound on this rental-ready model.
Locking casters ensure the unit stays in the ideal spot for operation and circulation. With total electric configuration, you can avoid the potential fire and fume hazards associated with fuel-fired heaters. Our 150kW heater also includes a phase monitor relay. The relay monitors all three phases of electricity used in the design to protect you and the equipment from voltage irregularities.
How It Works
Electric heaters rely on electrical resistors to generate their heat. Once you power up the heater, the electrical current flows to the heating coils inside. These coils act as resistors that help control the current's flow to maintain the desired heat level. The current becomes heat as it passes through the resistor.
In convection heaters like this one, a well-built blower helps circulate the hot air. A belt-driven motor powers the blower, producing higher revolutions per minute (RPM) to create a quieter, more efficient heating experience. Our model uses a plenum fan for high-capacity air movement. These fans send out high volumes of air in multiple directions simultaneously. Optional intake flanges draw in cooler ambient air, and the process begins again.
Specifications for Our 150kW Heater Rentals
Our 150kW heater is safe, dependable, and easy to operate. Explore the notable features:
Blower: The heater features a variable speed blower up to 10,000 cubic feet per minute (CFM) for powerful air movement.
Electrical: The heater operates on a three-phase, 60 Hertz, and 460 volts design. Choose between 75 or 150kW operation.
Dimensions: This model is 94" long, 34" wide, and 65" high.
Weight: The operating weight of this heater is 1,560 pounds.
Construction: This unit features an aesthetically pleasing stainless steel finish that's easy to clean.
Applications for 150kW Heaters
Our 150kW heaters provide a temporary emergency heating solution for businesses and institutions of all types. Rent one for:
Construction sites: Keep projects on schedule and costs down.
Buildings: Heat larger common areas or prevent potential pipe freezes.
Industrial sites: Add extra heat during prolonged cold snaps or continue operations in a new building when the temperature falls.
Organized events: Bring warmth to garages, tents, and other unheated spaces for planned events.
Scheduled maintenance: Avoid downtime with replacement heat during routine upkeep.
Equipment failure: Provide safe, alternative warmth when your furnace or other heat source suffers breakdowns or storm damage.
Technical Specifications
| Electrical Data |
460 volt/3 phase/60 Hertz 250 amp 600 volt single pole mount receptacles 185 FLA |
| Blower |
Variable speed (440-1760 RPM) up to 10,000 CFM Plenum fan arrangement Belt Drive 19" diameter outlet flange Optional 19" side air intake flange |
| Heat Control |
Programmable Logic Control 225° Temp Internal Thermostat 103° Temp Remote Thermostat On/Off Switch |
| Machine Control |
Hour meter Phase Monitor Relay 75 or 150kw operation Indicator lights (power/phase failure/air flow/heat/over temp) Blower speed control |
| General |
Stainless Steel Construction 10' lockable casters Fork lift pockets on all four sides |
Trust Temperature Control Rental Solutions for Your Needs
Keep employees, guests, or students safer and more comfortable with this temporary heating solution. Our comprehensive questionnaire makes it easy to ensure you get the correct equipment for your needs. From seamless delivery and installation to 24/7 emergency service, Temperature Control Rental Solutions is with you every step of the way. Contact one of our rental specialists to get started.
