RENTAL CHILLERS: 50-TON AIR COOLED
50-Ton Air-Cooled Chillers
Air-cooled chillers are among the most popular cooling methods in industrial and commercial sectors, primarily because of their high efficiency in large spaces. Operations like construction companies, manufacturing facilities, and warehouses prefer to use chillers because they provide significantly more cost savings than conventional cooling methods like air conditioners. Knowing the optimal size chiller for your operation is essential, as too much power and capacity can often lead to overspending and lower operating efficiencies.
At Temperature Control Rental Solutions (TCRS), our technical expertise is unparalleled in the industry. Our knowledgeable staff can help you select the optimal chiller unit for your operation. We leverage our 30 years of experience to furnish our customers with the best cooling solutions regardless of the type or size of operation.
How Our 50-Ton Air-Cooled Chillers Work
Air-cooled chillers absorb heat from process water and transfer it into the environment. The process begins when refrigerant enters the evaporator and changes into gas after heating. The gaseous refrigerant then travels to the compressor, where its pressure increases.
From there, the high-pressure refrigerant moves to the condenser. Fans push the warm air through the condenser to absorb the heat and release it into the environment. After the heat escapes, the pressure of the refrigerant lowers and begins a new cycle.
Air-cooled and water-cooled chillers function similarly, with the primary difference between the two is the substance used to accomplish chilling.
Benefits of Using Air-Cooled Chillers
Among the primary benefits of renting an air-cooled chiller over a water-cooled unit or other cooling options are:
Easy installation: Air-cooled chillers require no cooling tower to operate, meaning that the system setup is much quicker than water-cooled units.
Lower maintenance: Because air-cooled chillers have fewer operational components, their maintenance requirements are much lower.
Sustainable: The heat released from air-cooled systems is recyclable, making them ideal for outdoor equipment-cooling operations.
No water source needed: Air-cooled units do not depend on water to operate, so they're excellent in locations with limited water supply.
Specifications for Our 50-Ton Air-Cooled Chillers
These commercial and industrial air-cooled chiller rentals are among the most durable and dependable on the market. They are capable of enduring some of the most demanding environments and contain powerful four-scroll compressors. Other specifications include:
Capacity: This unit has an overall 58-ton operating capacity.
Range: Chilled water outputs range from 15.1 to 65 degrees Fahrenheit.
Dimensions: These chillers measure 9 feet, 9 inches long by 8 feet, 1 inch wide by 8 feet, and 7 inches high.
Weight: The operating weight of our 50-ton chiller is 5,860 pounds.
Flow: The flow range of this unit is 60-240 gallons per minute.
50-Ton Air-Cooled Chiller Applications
Our 50-ton rental units are ideal options for cooling control in a broad range of applications, including commercial buildings, manufacturing facilities, event spaces, warehouses, and more. They work well in various industrial processes like:
Wastewater treatment
Turbine inlet cooling
Concrete cooling
Environmental control
Dense air injection
Technical Specifications
|
Evaporator Data
EWT (˚F) LWT (˚F) Design Flow Rate (gpm) Pressure Drop (ft.) Fluid Water Volume (gal.) |
54.0°F 44.0°F 136 7.4 Water 6 |
|
Condenser Data
Ambient Temp. (˚F) |
95.0°F |
|
Electrical Data
Volts/Ph/Hz Min. Circuit Ampacity Min. Dual Element Fuse Size (Amps) |
460/3/60 135 FLA (Chiller) 11 FLA (Pump) 150 |
| Min/Max Flow GPM |
Min Flow 60 Max Flow 240 |
| Compressor Type: |
4 Scroll |
|
General
Capacity Refrigerant Chilled Water/Brine Temperature Range |
57 Tons R410A 15.1°F–65°F |
Rent a 50-Ton Air-Cooled Chiller From TCRS Today
At Temperature Control Rental Solutions, our knowledgeable and experienced team members are committed to making your rental experience as simple as possible. We'll help you determine which chiller or other cooling solution is the best for your application. Contact us online or call us at 877-343-8277 today to get started!
