RENTAL CHILLERS: 100-TON AIR-COOLED
100-Ton Air-Cooled Rental Chillers
If you have a temporary need for powerful cooling capabilities, our 100-ton air-cooled chiller rentals provide a convenient and cost-effective solution. These industrial refrigeration systems are ideal for chilling fluids in commercial and industrial applications. They are often used to cool equipment and serve in climate control applications for large areas like corporate event venues, warehouses, and manufacturing facilities.
At Temperature Control Rental Solutions (TCRS), we make it easy to get the temperature control you need. We'll provide you with a smooth process from start to finish with superior customer service and quality chiller systems delivered in rental-ready condition.
How 100-Ton Air Chillers Work
Air-cooled chillers are streamlined, self-contained refrigeration units designed to remove heat from water sources through absorption. They are compact and smaller than water-cooled chillers, making them a perfect solution for places where you have limited space and restricted water access.
This cooling equipment connects to an air handling system and draws water in, subjecting it to an evaporation process where heat is transferred away. Next, the chiller moves the water through a compressor, where it removes even more heat using fans. The collected heat discharges outside the machine.
The water comes out at a much cooler temperature on the other side. Once the cool water is used and warmed up again, it returns to the system, where the process repeats. You can choose to let the hot air you generate get released into the atmosphere or configure a system to harness it for use as an auxiliary heat source.
Specifications for Our 100-Ton Chiller Rentals
These industrial air-cooled water chillers are heavy-duty systems. They are designed to withstand rugged environments and are powered by three-phase electricity. Key specifications include:
Capacity: This unit has an overall 99.6-ton capacity.
Range: Chilled water outputs range from 30 to 65 degrees F.
Dimensions: These chillers measure 8'8" high, 7'7" wide, and 15'4" long.
Weight: The operating weight for our 100-ton water chiller is 10,723 pounds.
Flow: The minimum/maximum flow range is 100 to 400 gallons per minute.
Common Applications for 100-Ton Air-Cooled Chillers
Our 100-ton air-cooled chillers for rent are an excellent emergency or supplemental solution in multiple applications. They are commonly used for cooling buildings, warehouses, and event spaces and work well in a wide range of industrial processes, including:
Technical Specifications
|
Evaporator Data EWT (°F) LWT (°F) Design Flow Rate (gpm) Pressure Drop (ft.) Fluid Water Volume |
54.0 44.0 238.8 10.3 Water 58.9 gal |
|
Condenser Data Ambient temp. (°F) |
95.0 |
|
Electrical Data Volts/Ph/Hz Min. Circuit Ampacity Min. Dual Element Fuse Size (Amps) |
460/3/60 203.0 FLA (Chiller) 21 FLA (Pump) 250 |
| Min/Max Flow GPM |
Min Flow 100 Max Flow 400 |
|
Compressor Type: |
5 Scroll |
|
General Capacity Refrigerant Chilled Water/Brine Temperature Range |
99.6 Tons R410A 30°F-65°F |
Schedule a 100-Ton Air-Cooled Chiller Rental
If you have an emergency or a project or event coming up and need temporary heating or cooling power, talk to our team. Temperature Control Rental Solutions (TCRS) has years of experience serving customers nationwide. We'll help you determine which of our products will meet your requirements and deliver the best value based on your specific needs.
Browse our complete selection of chiller systems for rent to learn more about our 100-ton air-cooled chillers and the other systems we offer. To schedule a rental or get in touch, please send us a message using our contact form or call 877-343-8277.
